Special engineering.

· Wood, metal and aluminium processing
· Flat belt conveyors in the construction industry
· Plastic production plants

Flashing lights in the PMF series

Extremely bright, omnidirectional flashing lights with energy-saving LED technology and fresnel cover for wide light dispersion. Very high mechanical stability and many different fitting options.

Flash energy: 14 Joule
Robustness: IP 55 (vertical mounting)
Operating temperature: –30 °C to +55 °C

Flashing lights in the PMF series

PMF 2020 / 2015

Sounders in the DS series

Multipurpose hazard warning devices with good penetration of acoustic barriers such as walls and doors. For signaling emergency shutdown and other machine states. 32 selectable basic tones, 10 year guarantee.

Sound pressure level: 105 dB(A), 110 dB(A)
Robustness: IP 66, IP 67, IK08
Operating temperature: –40 °C to +55 °C

Size of acoustical coverage (A x B x C in meter)

80 dB (A) 85 dB (A) 90 dB (A)
有 DIN 声响和所需声级的覆盖区域。

The figures shown are mainly for a quick orientation. For an individual and precise interpretation please use Pfannenberg Sizing Software (PSS).

Sounders in the DS series

DS 5
DS 10
